Add/Remove	TYPE	Min Bore Dia	d	H	L	S	E
	S08K SCLCL/R-06	10	8	7	125	5	14
	S10K SCLCL/R-06	12	10	9	125	6	14
	S12M SCLCL/R-06	13	12	1	150	7	25
	S16Q SCLCL/R-06	20	16	15	180	11	32
	S20R SCLCL/R-06	25	20	18	200	13	38
	S25R SCLCL/R-06	32	25	23	200	17	45
	S25R SCLCL/R-12	32	25	23	200	17	45
	S32S SCLCL/R-12	40	32	30	250	20	50
	S40S SCLCL/R-12	50	40	37	250	27	60

Add/Remove	TYPE	Min Bore Dia	d	H	L	S	E
	S12MSSKCL/R-09	16	12	11	150	9	26
	S16QSSKCL/R-09	20	16	15	180	11	32
	S20RSSKCL/R-09	25	20	18	200	13	34
	S25RSSKCL/R-12	32	25	23	200	17	36
	S32SSSKCL/R-12	40	32	30	250	22	43

Add/Remove	TYPE	Min Bore Dia	d	H	L	S	E
	S10KSTFPL/R-11	12	10	9	125	6	22
	S12MSTFPL/R-11	16	12	11	150	8	25
	S16QSTFPL/R-11	20	16	15	180	10	30
	S20RSTFPL/R-16	25	20	18	200	12	35

Add/Remove	TYPE	Min Bore Dia	d	H	L	S	E
	S10KSTWPL/R-11	12	10	9	125	6	23
	S12MSTWPL/R-11	16	12	11	150	8	30
	S16QSTWPL/R-11	20	16	15	180	10	35
	S20RSTWPL/R-11	25	20	18	200	12	40

Add/Remove	TYPE	Min Bore Dia	d	H	L	S	E	f
	S16QSDZCL/R-07	20	16	15	180	11	30	3.5
	S20RSDZCL/R-07	25	20	18	200	13	35	3.7
	S25RSDZCL/R-11	32	25	23	200	17	45	6.5
	S32SSDZCL/R-11	40	32	30	250	30	45	7
	S40SSDZCL/R-11	50	40	37	250	32	55	6.5

Add/Remove	TYPE	Min Bore Dia	d	H	L	S	E	f
	S10KSDQCL/R-07	13	10	9	125	8	20	2.5
	S12MSDQCL/R-07	16	12	11	150	9	22	3.5
	S16QSDQCL/R-07	20	16	15	180	11	27	4
	S16QSDQCL/R-11	20	16	15	180	11	32	4
	S20RSDQCL/R-11	25	20	18	200	13	32	4.5
	S25RSDQCL/R-11	32	25	23	200	17	32	7

Add/Remove	TYPE	Min Bore Dia	d	H	L	S	E
	S16QSVUBL/R-11	20	16	15	180	11	30
	S20RSVUBL/R-11	25	20	18	200	13	35
	S25RSVUBL/R-11	32	25	23	200	17	40
	S32SSVUBL/R-16	40	32	30	250	22	50
	S40SSVUBL/R-16	50	40	37	250	27	55

Add/Remove	TYPE	Min Bore Dia	d	H	L	S	E
	S10KSTFCL/R-09	13	10	9	125	7	20
	S12MSTFCL/R-09	16	12	11	150	9	25
	S12MSTFCL/R-11	16	12	11	150	9	25
	S16QSTFCL/R-11	20	16	15	180	11	30
	S20RSTFCL/R-11	25	20	18	200	13	35
	S20RSTFCL/R-16	25	20	18	200	13	35
	S25RSTFCL/R-16	32	25	23	200	17	40
	S32SSTFCL/R-16	40	32	30	250	22	50
	S40SSTFCL/R-16	50	40	37	250	27	60

Add/Remove	TYPE	Min Bore Dia	d	H	L	S	E	f
	S10KSDUCL/R-07	13	10	9	125	8	20	2.5
	S12MSDUCL/R-07	16	12	11	150	9	22	3.5
	S16QSDUCL/R-07	20	16	15	180	11	27	4
	S16QSDUCL/R-11	20	16	15	180	11	27	4
	S20RSDUCL/R-11	25	20	18	200	13	35	4.3
	S25RSDUCL/R-11	32	25	23	200	17	40	6.8
	S32SSDUCL/R-11	40	32	30	250	17	50	8.4

Add/Remove	TYPE	Min Bore Dia	d	H	L	S	E
	S16QSVUCL/R-11	20	16	15	180	11	30
	S20RSVUCL/R-11	25	20	18	200	13	35
	S25RSVUCL/R-11	32	25	23	200	17	40
	S32SSVUCL/R-16	40	32	30	250	22	50
	S40SSVUCL/R-16	50	40	37	250	27	55

< tbl="table11" td class="TableData" align="center" valign="middle" colspan="1">S40SBCLNL/R-12

Add/Remove	TYPE	Min Bore Dia	d	L	S	E
	S32SBCLNL/R-12	40	32	250	22	50
	50	40	250	27	60

Add/Remove	TYPE	Min Bore Dia	d	H	L	E
	S1005HSWUBL/R06-06	6	10	9	100	21
	S1006HSWUBL/R06-07	7	10	9	100	21

Add/Remove	TYPE	Min Bore Dia	d	H	L	S	E
	S25RSWLCL/R-06	32	25	23	200	17	40
	S32SSWLCL/R-08	40	32	30	250	22	55

Add/Remove	TYPE	Min Bore Dia	d	H	L	S	E
	S12MSVJCL/R-08	16	12	11	150	9	25
	S16QSVJCL/R-08	20	16	15	180	11	30

Add/Remove	TYPE	Min Bore Dia	d	L	S	E
	S25RBTUNL/R-16	32	25	200	17	45
	S32SBTUNL/R-16	40	32	250	22	50
	S40SBTUNL/R-16	50	40	250	27	60

Add/Remove	TYPE	Min Bore Dia	d	L	S	E
	S20RBTQNL/R-16	25	20	200	13	40
	S25RBTQNL/R-16	32	25	250	17	45
	S32SBTQNL/R-16	40	32	250	22	50
	S40SBTQNL/R-16	50	40	250	27	60

Add/Remove	TYPE	Pitch Dia	d	S	L	E
	SIR/L008K08	9	16	6.4	125	24
	SIR/L001H11	12	10	7.4	100	-
	SIR/L0010K11	12	16	6.5	125	30
	SIR/L0012K11	15	12	8	125	36
	SIR/L0012M16	16	16	10	150	36
	SIR/L0016P16	19	16	11.4	170	-
	SIR/L0020P16	24	20	13.4	170	-
	SIR/L0025R16	29	25	16.4	200	-
	SIR/L0032S16	36	32	19.6	250	-

Add/Remove	TYPE	Min Bore Dia	d	L	S	E
	S32SBCKNL/R-12	40	32	250	22	50
	S40SBCKNL/R-12	50	40	250	27	60
